Product Specification
|
MODEL |
SVH50 |
SVH50C |
SVH50CS |
|
Engine brand |
HONDA GX270 |
CHANGCHAI/CHANGFA CF178 |
CHANGCHAI/CHANGFA R180 |
|
Engine Model |
Gasoline & Single Cylinder & Vertical & Four Stroke & Overhead Valves |
Diesel & Single Cylinder & Vertical & Four Stroke & Direct injection |
Diesel & Single Cylinder & Vertical & Four Stroke & Water cooling |
|
Power |
6.7kw |
4.4kw |
5.7kw |
|
Rotating Speed |
3600rpm |
3600rpm |
2600rpm |
|
Fuel Capacity |
5.9L |
2.7L |
6.5L |
|
Lubricating Oil |
1.1L |
1.1L |
2L |
|
Start up |
Hand recoil / electric start |
Hand start, electric start |
|
|
Static Load |
45n/cm |
||
|
Vibration Frequency |
70hz |
||
|
Nominal Amplitude |
0.6mm |
||
|
Exciting Force |
20kn |
||
|
Walking Way |
Two-way hydraulic & chain drive |
||
|
Walking Speed |
0-3.8km/h |
||
|
Theoretical Climbing Ability |
30% |
||
|
Hydraulic Tank Capacity |
18L |
||
|
Water Tank Capacity |
20L |
20L |
/ |
|
Watering System |
Gravity watering |
Gravity watering |
/ |
|
Wheel Size |
426*600mm*2 |
||
|
Full Width |
780mm |
||
|
Machine Length(protective Frame Dumping) |
2480mm |
||
|
Machine Height(protective Stand Erect) |
1820mm |
||
|
Package Size |
1600*850*1900mm |
||
|
Weight |
540kg |
540kg |
570kg |
