POWER:100KVA Japan HAMAN ディーゼル発電機SUPER SILENT Diesel Generator

JAPAN HAMAN SUPER SILENT Diesel Generator, equipped with YANMAR technology four cylinders engine, powerful and low fuel consumption. With 60°C radiator, even if you use it in high-temperature area, it still maintain great performance. U.K. Stamford technologh high-quality brushless alternator, 100% power, all cooper wire.

Porduct Specification
Generator Set Specification
Model    HM-100TA3
Prime Power    100KVA
Standby Power 108KVA
Voltage    400/230v(voltage can be customized)
Frequency    50/60HZ
Rated Current(A)    159
Rated Speed    1500
With Diesel Engine
Brand&model    HM48GBZL
Engine Type    4 Cylinders, in line, water cooled
Prime Power    88KW
Bore*Stroke    108×132mm
Displacement    4.75L
Working Mode    Natural aspiration
Starting system    12V Electric
Fuel Consumption(g/KW.H)    208
With Alternator
Optional Brands    Leroy Somer/HAMAN/Stamford
Alternator Model    274E
Power factor    0.8
Loop Mode    Three phase four line
Insulation Grade    H
Excitation Type    Brushless self-excited constant voltage (AVR)
Pole No.    4
With Genset
Control System    Digital Controller
Output Voltage(V)    400/230
Noise Level db(A)7m    68
Fuel Tank Capacity(L)    280
Overall Dimension(mm)    2900×1150×1750
Net Weight (Kg)    1880
